2500W Tiny House Solar Kit

Name: 2500W Tiny House Solar Kit
Brand: Renogy
SKU: RKIT2500D-CLFP-US
Price: 6599.99 USD
Availability: InStock

$6,599.99

$7,899.99

Save $1,300.00

Quantity

We accept

25-Year 80% Output Warranty

Buy with confidence knowing that your solar investment will last for the long haul.

Product info

For those seeking a convenient way to operate standard household devices off-grid, the Renogy Home Cabin Kit offers a comprehensive solution. This kit enables you to supply power to a variety of essential and luxury appliances throughout the day, supporting a reliable and sustainable off-grid lifestyle.

The included 48V 3500W Solar Inverter Charger brings two key enhancements: it converts DC electricity into AC for use with typical home appliances, and it also provides the option to charge from an AC power source or the grid.

Additionally, the newly integrated BT-2 Bluetooth Module lets you monitor your system’s performance in real time through the Renogy DC HOME app on your smartphone.

This Kit is also available with 4 320W panels instead of 8!

This kit includes:

8*1 Piece of 320 Watt Monocrystalline Solar Panel

4*40Ft 10AWG Solar Panel to Charge Controller Adaptor Kit (Pair)

1*5 Strings Solar Combiner Box

4*16A 1P DC Miniature Circuit Breaker

1*DC Circuit Breaker Box

1*50A 1P DC Miniature Circuit Breaker

1*16Ft 10AWG Battery to Charge Controller Tray Cables for 3/8 in Lugs (Pair)

2*8Ft 8AWG Solar Stranded Copper PV Wire

1*160A 2P DC Molded Case Circuit Breaker

1*48V 3500W Solar Inverter Charger

2*8Ft 1AWG Copper Battery Inverter Cables for 3/8Inch Lugs (Pair)

1*BT-2 Bluetooth Module

4*12V 200Ah Core Series Lithium Battery

3*1AWG 12Inch Copper Battery Interconnect Cable

The Specs:

320 Watt Monocrystalline Solar Panel

Maximum Power at STC: 320W

Optimum Operating Voltage (Vmp): 32.7V

Open-Circuit Voltage (Voc): 40.1V

Optimum Operating Current (Imp): 9.79A

Short-Circuit Current (Isc): 10.36A

Operating Temperature: -40°F to 185°F

Cell Efficiency: 21%

Maximum System Voltage: 1000V DC (UL)

Maximum Series Fuse Rating: 15A

Weight: 39.7lbs

Dimensions: 65.6 x 39.4 x 1.4 in

Certifications: CE, ISO, UL

RENOGY 48V 3500W SOLAR INVERTER CHARGER WITH 80A/145V MPPT

Output Waveform: Pure Sine Wave

Continuous Output Power: 3500W

Peak Power Rating: 7000W

Output Voltage: 120VAC±5%

Output Frequency: 50 Hz ± 0.3% 60 Hz± 0.3%

Input Voltage / Rated Battery Voltage: 48VDC (minimum start-up voltage 44V)

Charge Controller Type: MPPT

Maximum Input Power: 4800W

Maximum Input Current: 50A

Dimensions: 16.8*12.7*4.9 in / 426*322*124 mm

Weight: 23.8 lbs /10.8kg

RENOGY 12V 200AH CORE SERIES DEEP CYCLE LITHIUM IRON PHOSPHATE BATTERY

Rated Capacity (0.5C, 25°C): 200Ah

Nominal Voltage: 12.8V

Energy: 2560Wh

Cycle Life (0.5C/1C, 25℃): 5000 Cycles (80% DOD, 80% EOL)

Charge Voltage: 14.4V

Maximum Continuous Charge Current: 100A

Dimension (L x W x H): 20.55 x 9.45 x 8.62 in / 522 x 240 x 219 mm

Weight: 47.3 lbs. / 21.45 kg

Terminal Bolt Size: M8 x 1.25 x 15 mm

Protection Rating: IP65

WARRANTY INFORMATION

Panels: 25-year power output warranty: 5 year 95% output warranty, 10 year 90% output warranty, 25 year 80% output warranty 10-year material and workmanship warranty

Accessories: 1-year material and workmanship warranty

Shipping

Fast & Free Shipping Nationwide

We offer free shipping on all orders within the continental U.S. through our network of warehouses. Once you place your order, you’ll receive a confirmation email, and we’ll begin processing it right away.

For most items, you can expect them to ship within 2-4 business days. Delivery typically takes an additional 3-7 business days, either through FedEx or USPS. Please keep in mind that weather, traffic, carrier troubles, or other unforeseen circumstances can affect shipping times.

We’re committed to making the shipping process smooth and worry-free so you can enjoy your new solar products without delay!

Warranty

Comprehensive Warranty for Peace of Mind

We stand behind the quality of every product we sell, offering a full manufacturer’s warranty to ensure lasting performance.

Please check out the warranty page below for a detailed breakdown of warranties for each product.

Happy with results

They're pretty big but only need to wire up two of them and they perform amazing. Definately buying more.

straightforward install with great performance

Easy setup and performs really well so far.

Good quality

Got exactly what I ordered. Really solid panels.

FAQs

Where are you located and where do you ship?

We are US owned and operated with our main headquarters located in Phoenix, Arizona. We ship orders anywhere within the continental US from our distributed network of warehouses operated by our logistics partners in California.

How much is shipping?

We're proud to provide FREE SHIPPING on all of our products throughout the Continental United States.

When will my products arrive?

Within 1-2 weeks if you order today. Once your order leaves the warehouse, depending on where you're located, transit time will take between 3-7 business days.

What happens after I place my order?

As soon as you place your order, you will receive an email from us with your confirmation details. Please keep this email for your records. After we receive your order we will begin preparing your order for shipment. As soon as your order ships, you will receive an email with tracking information. For larger items you will receive a phone call from the delivery team to schedule your delivery appointment. You must be home to accept and sign for the delivery during your appointment as scheduled.

When will my products arrive?

Within 1-2 weeks if you order today. Once your order leaves the warehouse, depending on where you're located, transit time will take between 3-7 business days.

Do you offer installation?

Installing our products may require specialized skills or additional tools, which are not supplied by Aureus Solar. Any installation expenses or fees resulting from improper setup or usage are not covered by us. Customers are responsible for carefully following all installation guidelines and ensuring they have the necessary equipment and expertise before beginning the process.

If you are not experienced with technical installations, we highly recommend hiring a qualified professional. Aureus Solar cannot be held responsible for any damages, losses, or extra costs that may arise from incorrect installation or misuse of our products.

Essential Tools for Solar System Installation and Maintenance

Having the correct tools is crucial-not only for convenience but also for the safety, efficiency, and longevity of your solar setup.

Multimeter
Use: Measures voltage, current, and resistance, making it indispensable for troubleshooting and system diagnostics.
Recommended features: DC/AC measurement, continuity testing, auto-ranging, and a clamp function for measuring current without disconnecting wires.
MC4 Crimping Tool and MC4 Connectors
Use: Necessary for attaching and maintaining MC4 connectors, which are the standard for solar panel wiring.
Note: A quality crimping tool ensures secure, weatherproof connections.
Cable Ties and Cable Management Accessories
Use: Keep wiring neat, organized, and protected from wear, reducing the risk of electrical issues over time.

Please note that Aureus Solar does not supply or reimburse for these tools. However, having them on hand can greatly assist with troubleshooting and maintaining your system, helping to ensure both safety and optimal performance.

Do you provide financing?

We sure do! To access your financing offer, please select Shop Pay Installments as your payment method in Step 3 of the checkout process. Please note that you will need to input a debit card to receive your offer but you can still back out after that step.

What is the warranty period for my purchase?

All Aureus Solar customers receive full manufacturer warranty coverage, as Aureus Solar is an authorized distributor for every brand offered on our website. This means you are entitled to the complete manufacturer warranty for each product purchased through us.

Please note that certain manufacturers may require customers to pay for return shipping on warranty claims made after the initial 30-day period. If you encounter any product issues, our team is available to assist you in coordinating directly with the manufacturer. For detailed warranty terms, always consult the product manual or the manufacturer’s warranty documentation included with your purchase.

Warranty Duration:
Warranty periods vary depending on the manufacturer and specific item. For most solar panels, product warranties typically cover 10–25 years, with performance warranties often guaranteeing at least 80% of original output by the end of the term. Inverter, battery, and accessory warranties may differ, so refer to the included documentation for exact timelines.

If you need to file a warranty claim, you may contact the manufacturer directly or submit a support request through Aureus Solar by sending an email to support@aureussolar.com. Please be aware that submitting a support request does not guarantee immediate approval of a replacement or repair. Our technical support team will review your request and may request additional information to help troubleshoot or document the issue, as required by the manufacturer.

To process a warranty claim efficiently, please be prepared to provide the following details:

Product serial number
Date of purchase
Any warning, error, or fault messages
A description of the problem
Photos or videos that help identify the issue

Coverage Outside the Lower 48 States:
Manufacturer warranties generally apply only within the contiguous 48 states of the U.S. If you require warranty service outside this area, you will need to send the product to the mainland at your own expense. Customers are responsible for all shipping costs to and from the manufacturer for warranty, repair, or replacement services. Using freight services is recommended for transporting items from your location to the manufacturer.

For the most accurate and up-to-date information, always review the warranty terms provided with your product and contact Aureus Solar for assistance as needed.
